Jeio Tech BS2 Shaking Heating Bath (37L), 230V

Jeio Tech BS2-20 Shaking Heating Bath (37L), 230V

Introducing the Jeio Tech BS2-20, a 37-liter shaking heating bath designed for precision, performance, and user convenience in a laboratory setting. This versatile unit combines accurate temperature control with consistent shaking motion, making it ideal for a wide range of applications including cell culture, hybridization, and various biochemical reactions.

Key Features

Exceptional Performance & Precision

• Wide Temperature Range: Operates from ambient +5°C up to 100°C, accommodating diverse experimental needs.
• Accurate Temperature & Speed Control: Delivers precise control over temperature (up to 100°C) and shaking speed (up to 200 rpm). The shaking motion ensures excellent temperature distribution, maintaining a stability of ±0.1°C at 50°C.
• Advanced Calibration: Features 3-point temperature calibration and 1-point shaking calibration for enhanced accuracy and reliable results.
• Optimized Thermal Control: Utilizes an optimal PID controller and a specialized bath structure that promotes smooth water circulation, ensuring uniform heating across all samples.
• Large Sample Capacity: The bath's extended height is designed to accommodate larger sample volumes, including flasks up to 2.8L.

Unmatched Convenience

• Intuitive Operation: A full-color touch display makes setup and operation effortless.
• Automated Timer: Program run times with the automatic On/Off timer for up to 999 hours and 59 minutes, allowing for unattended operation.
• Smart Design: The transparent, gable-roof-shaped cover prevents condensed water from dripping onto samples, protecting their integrity. A side-located drain port offers easy access for cleaning and water changes.
• Data Connectivity: A standard USB port allows you to connect the unit to a PC for seamless data recording and process monitoring.
• Included Accessories: Comes standard with a durable, corrosion-resistant spring wire rack to securely hold a variety of flasks and tubes.

Advanced Safety Features

• Comprehensive Alarms: Equipped with audible and visual alarms that alert the user to water shortages, temperature and RPM deviations, or sensor abnormalities.
• Automatic Shutdown: The heater automatically shuts down in the event of low water levels to prevent damage to the unit and ensure user safety.
• Electrical Protection: Integrated over-current and short-circuit protection safeguards the device from electrical faults.

Optional Enhancements

• Mobile Monitoring: Remotely monitor real-time temperature and RPM via an optional mobile monitoring system for ultimate flexibility.
• GMP/GLP Compliance: For regulated environments, the unit can be integrated with the optional LC DataKeeper software, which is 21 CFR Part 11 compliant and ideal for GMP audits.

Technical Specifications

• Model: BS2-20
• Catalog No.: AAH44205K
• Bath Volume: 37 L / 1.3 cu ft
• Working Temperature Range: Ambient +5°C to 100°C / Ambient +9°F to 214°F
• Temperature Stability (at 50°C): ±0.1°C / ±0.20°F
• Shaking System: Reciprocal motion
• Frequency Range: 32 to 200 rpm
• Stroke Length: 30 mm / 1.18 inches
• Bath Dimensions (W×L, D): 300 x 520 mm, 235 mm / 11.8 x 20.5 inches, 9.3 inches
• Exterior Dimensions (W×L×H): 746 × 417 × 426 mm / 29.4 × 16.4 × 16.8 inches
• Net Weight: 31 kg / 68 lbs
• Electrical Requirements: 230V, 60Hz, 8.9A
