Device Overview

The LogTag TRED30-16R is a high end temperature data logger designed for applications where temperature monitoring is critical. Whether it’s vaccines in medical refrigerators, pharmaceuticals in transport or sensitive food products, the LogTag TRED30-16R delivers accurate and reliable temperature readings. As part of the trusted LogTag TRED30 series, this model incorporates the latest in data logger technology including smart probe compatibility for continuous and uninterrupted logging. The smart probe ready version, such as the LogTag TRED30-16CP, allows seamless integration with the LogTag CP110 Smart Probe so temperature data is captured even during probe changes or maintenance. With its rugged design and proven performance, the LogTag TRED30-16R is the go to solution for professionals who demand temperature data logging in critical applications.

Technical Specifications

Versatile and reliable, the LogTag TRED30-16R has a range of technical specifications to meet your monitoring needs:

• Operating Temperature Range: Designed for tough environments, the LogTag TRED30-16R operates from -40°C to +99°C (-40°F to +210°F).

• Data Storage Capacity: Stores up to 15,900 temperature data readings so you can capture detailed temperature data logger data for short term and long term monitoring. If you require greater capacity or a waterproof solution, consider our Submersible Data Logger options.

• Accuracy: Rated temperature reading accuracy of better than ±0.5°C in the critical -20°C to +40°C range to meet regulatory standards and give you peace of mind for sensitive applications.

• Power Source: Powered by a replaceable coin cell battery, the LogTag TRED30-16R has a typical battery life of months of continuous operation so minimal maintenance and no downtime.

• Data Download: Download logged data to a computer or readout device using the standard LogTag Interface cradle and LogTag Analyzer software. Quick and easy to review, archive and share temperature data.### Key Features and Benefits

The LogTag TRED30-16R has features to simplify temperature monitoring and rapid response to temperature excursions:

• Audible Alarm: The built in audible alarm will sound immediately if temperature readings are out of range, alerting you to potential excursions.

• LCD Display: The easy to read LCD display shows current temperature reading, current time, recording status and battery status. It also shows alarm status so you can quickly see if temperature excursions have occurred.

• Simplified Alarm Clearance: Address and reset alarms is easy with the simplified alarm clearance stop and start procedure. This reduces the risk of missed alarms.

• Statistics History: View statistics history directly on the device, up to 30 days of temperature excursions and day summary statistics memory. For reliable monitoring of ultra-low freezers, consider the UTREL-16 Ultra-Low Freezer Temp Data Logger, NIST Certificate. This visible record of excursions supports compliance and quality assurance.

• Smart Probe Compatibility: The LogTag TRED30-16CP model is smart probe ready, no need to recalibrate and continuous and uninterrupted logging even during probe changes.

• Auto-Pause Function: Suspends alarm and statistics processing when external probe is disconnected, no false alarms and data integrity is maintained.

• External Probe: Use an external probe for flexible placement and accurate measurement even in hard to reach or remote locations.

These features combined with robust processing and user friendly interface makes the LogTag TRED30-16R a powerful tool for anyone who needs temperature monitoring and a visible record of excursions.

Meets CDC / VFC Vaccine Monitoring Guidelines

LogTag® TRED30-16R is a CDC / VFC compliant ISO/IEC 17025 NIST traceable temperature data logger used to monitor & record temperatures of vaccines in refrigerators or freezers. The LogTag TRED30-16R measures and stores up to 15.9K readings over a temperature range of -40° to +99°C (-40° to +210°F) via external bottle probe. The display shows at-a-glance status updates, temperature readings, alarm conditions and historical data, if excursions have occurred during the current day and up to the previous 29 days. The display shows current temperature reading, current time, recording status and battery status. The alarm is trigged if temperature readings are out of range. The status indicator changes from a ✔ to an X and, if configured, the audible alarm will sound. The day marker will also appear if not already present. The alarm status indicator and audible alarm can be cleared, but the day marker remains to ensure a visible record of excursions is shown on the display. A simplified alarm clearance, stop & start procedure is available as an option. Details of any excursions in the preceding 30 days can be checked directly by inspecting the statistics history on the recorder’s display or in more detail by downloading, interpreting and managing the logged data via a standard LogTag® Interface cradle to LogTag Analyzer software.

Note: The TRED30-16R replaces the TRED30.

Summary of TRED30-16R changes

• Built-in audible alarm.

• New, easy to read LCD display with 30 day summary in calendar format

• Up to 15.9K recordings – Enough memory for 66 days at 6 minute logging.

• Auto-pause function – unplugging the external probe automatically suspends alarm & statistics processing.

Certification and Compliance

The LogTag TRED30-16R is designed to meet the highest regulatory requirements, making it perfect for vaccine monitoring, food safety and other critical applications. It is fully ISO/IEC 17025 NIST traceable so every temperature reading is accurate and reliable for audit and reporting purposes. It is also FDA food contact rated so it can be used in environments where direct or indirect contact with food is possible. By exceeding CDC and VFC guidelines the LogTag TRED30-16R gives you peace of mind that your temperature monitoring is compliant with the latest industry standards. Whether in healthcare, pharmaceuticals or food service this data logger has the performance and certification to protect your products and maintain regulatory confidence. For those requiring additional compliance, consider the 21 CFR Part 11 Compliant USB Thermocouple Data Logger.
