Gilson 8in Sieve, Brass/Stainless, Full Height, 0.530in
Our high-quality testing sieves are designed for precision, durability, and consistent fit, meeting accurate specifications with robust brass construction. Each ASTM Test Sieve comes with a Certificate of Compliance.
The 8" Full Height Sieves feature an overall height of 2-5/8 inches and a 2-inch depth, measured from the top of the mesh to the top of the sieve.
The 8-inch (203mm) diameter ASTM E11 Test Sieve includes stainless steel woven-wire cloth with 0.530-inch (13.2mm) openings and a full-height brass frame. Its overall height is 2-5/8 inches, with a stacked height of 2-1/8 inches.
Features:
- Individually serial numbered
- Compliant with ASTM E11 requirements for Compliance Sieves
Included Items:
- 8” Sieve, Brass/Stainless, Full Height, .530”
- Certificate of Conformance to ASTM E11 requirements
Accessories:
- Sieve Pans - nest underneath sieves to collect fines
- Sieve Covers - prevent sample loss during agitation
- Verification Services - provide NIST traceable documentation of opening sizes
Sieve Specifications
- Sieve Frame Diameter: 8in (203mm)
- Frame Height: Full Height
- Stacked Frame Height: 2-1/8in
- Overall Frame Height: 2-5/8in
- Material: Brass Frame / Stainless Steel Cloth
- ASTM E11 Opening Size: 0.530in (13.2mm)
- Backing Cloth Included: No
- Estimated Shipping Weight: 2.0lb (0.91kg)
