Basic Mikro Air Jet Sieve AJ-103B for 8in Test Sieves
The Basic Mikro AJ-103B is a single-sieve air jet analyzer for particle size analysis of dry powders. This model is configured for ASTM E11 8in (203mm) test sieves and processes one sieve at a time.
A rotating slotted nozzle directs air through the covered sieve to disperse the sample. An external vacuum draws air and undersize material through the mesh. Select the sieve opening and test conditions for the material and laboratory procedure.
Core Specifications
- Model: AJ-103B
- Sieve diameter: 8in (203mm)
- Sieve capacity: one sieve
- Listed sample mass: 10–100g
- Listed particle size range: No. 4–No. 635 (4.75mm–20µm)
- Application: dry powders
Vacuum System Required
An external vacuum system is required for operation and is purchased separately. Confirm the vacuum selection for the sample material and operating conditions before ordering.
The Mikro Air-Jet Cyclone Collector is a separately sold accessory for collecting undersize material. It does not replace the required vacuum system.
Confirm the Configuration
Compare air jet sieve equipment when choosing a model. Confirm sieve-frame compatibility, supplied accessories and electrical requirements for the exact unit; do not substitute a 200mm configuration based on nominal size similarity.
