Aquafog SST Flowmeter Panel, 3-15 GPH

Aquafog SST Flowmeter Panel, 3-15 GPH

Recommended for A-XE-2000-C and A-XE-2000-RF-Exp Aquafog TurboXE Fogging Fan

Turbo XEs come with a visual flowmeter panel of your choice.

The flowmeter panel connects to a pressurized water supply and allows the operator to monitor and adjust the water feed rate going to the XE atomizer. A precision needle valve regulates the flow, while the clear polycarbonate meter provides easy visual confirmation of system operation.

Explosion-proof direct-feed fogger units should always be paired with an appropriately rated explosion-proof water shutoff valve. This ensures water flow stops automatically whenever power to the unit is interrupted or cycled off. Because explosion-proof control components vary by installation and area classification, shutoff valves, controls, receptacles, and associated electrical components must be provided by the customer or installing contractor.

Lower feed rates generally produce a drier, finer fog. Higher feed rates produce heavier fog, larger droplets, and more drain-off.

Specifications:

• Flowmeter Scale 3 to 15 GPH
• Best Operating Zone (GPH) Mid-scale to 15
• Net Fogging Output (GPH) Up to 10
• Drain Discharge (GPH) Up to 5
• Average Particle Size 10 - 15 Microns
• Fog Character General humidification

Selection Tip: If in doubt, do not automatically choose the largest flowmeter. Select the smallest meter that comfortably covers your intended feed rate.

Important: At higher feed rates, excess water is discharged through the drain tube and droplet size increases. Lower-range meters are generally preferred for dry fog and humidification work, while higher-range meters are better suited for high-output evaporative cooling applications.

Water Control Note: Explosion-proof direct-feed Turbo XE fogger units should always include an appropriately rated explosion-proof shutoff valve (or equivalent control device) to automatically stop water flow whenever power to the unit is interrupted or cycled off. All electrical controls, shutoff valves, plugs, and receptacles must be customer supplied and matched to the site’s required hazardous location classification.
