Powerful driving system with a durable body increases shaking structure. Suitable for larger or heavier workloads requiring accurate and reproducible results.
Performance
- Microprocessor PID control.
- Intelligent speed controller enables reproducible results.
- Shaking speed calibration enables matching the displayed rpm to the reference point.
- Competitive high shaking speed up to 500 rpm.
- Orbital shaking motion in various diameter.
- 19.1mm or 25.4mm for OS-4000
- 25.4mm for OS-7100
- 50.8mm for OS-7200
- Wide speed range even with heavy workload.
- Ideal DD (Direct Drive) Brushless Motor and triple cam system support heavy load, quiet, maintenance free operation and deliver high torque at high speeds and smooth rotation. (for OS-7100/7200)
- Equipped with a maintenance-free BLDC motor to generate smooth, quiet, uniform, and yet powerful shaking motion. (for OS-4000)
- Best effort run function intelligently manages its rpm to keep shaking even workload is out of its capacity.
- Automatic shaking speed adjustment in case of excessive workload such as unbalanced load placement, unusual vibrations caused from unstable floor or external shock.
- Pleasant test environment by the smooth acceleration and deceleration control.
- Smooth start and smooth stop function prevent chemical spills from flasks or test tubes.
- Low-profile design minimizes vibration or sliding caused by the high speed shaking motion.
Convenience
- User friendly control panel.
- Lab Companion’s unique VFD-bright, clear, easy to read.
- Durable membrane touch switch and control knob.
- Easy-set digital timer. (1 min. to 999 hr. 59 min.)
- Repetitive task can be easily performed as the platform stops where it starts.
- Stopping the shaking platform always at the same position is highly beneficial for automated dosing or sampling process.
- Speed is basically set and displayed in increments of 1 rpm. Also speed increment interval can be set among 1, 5, 10 rpm according to users preference.
- Built-in RS-232 port and USB port for external control and data collection.
- Variety of accessories are available to meet application demands.
Safety
- Automatic run after power interruption.
- Shaking speed deviation alarm.
- Over-current protection, Stalled pla orm check. (stalled platform check is for OS-4000)
View the full line of Laboratory Shakers, Advanced Orbital Shakers, Heating Shakers, Incubated Shakers, Open Air Shakers, Rocking Shaker, Microplate Shaker, and Shaker Accessories for the Lab
