Dayton Superior Tilt Bracket, 7in (100/Ct)

Dayton Superior Tilt Bracket, 7in (100/Ct)

Category: Accessories | Tilt-Up Construction Brand: Dayton Superior

Product Overview

Revolutionize your tilt-up construction projects with the Dayton Superior Tilt Bracket, a patented forming system (US Patent #8186645) designed for superior efficiency, accuracy, and cost-effectiveness. This innovative system replaces traditional, labor-intensive wood forming methods with lightweight, reusable plastic components, streamlining your workflow and reducing material waste.

The system consists of two main parts: a durable plastic bracket and a disposable, adhesive-backed shoe plate. The shoe plate sticks firmly to the casting slab, creating a secure anchor point. The bracket then simply snaps into the shoe plate, ready to hold the form board in place. This design eliminates the need for drilling, nailing, and extensive bracing, allowing for faster setup and breakdown times. With a maximum recommended spacing of 18 inches, the Tilt Bracket™ system ensures structural stability while minimizing material costs.

Key Features & Benefits

• Patented Tilt-Up Forming System: Say goodbye to cumbersome wood forms. This cutting-edge system is engineered for speed and precision, helping you complete projects faster and with fewer resources.
• Lightweight & Reusable Brackets: Crafted from high-impact, durable plastic, the brackets are easy to handle and can be reused on multiple jobs, offering significant long-term savings and reducing on-site waste.
• High-Strength Adhesive Shoe Plate: The single-use shoe plate features a powerful adhesive base that provides a reliable, firm hold on the casting slab without the need for mechanical fasteners. This prevents movement and ensures your forms remain perfectly aligned. (Sold separately V092.123465-Carton)
• Versatile Sizing for Various Applications: The Tilt Bracket™ system is available in two sizes to accommodate common lumber dimensions and a wide range of slab thicknesses:
  • 5" Bracket: Ideal for form heights from 5" to 7". (sold separately)
  • 7" Bracket: Designed for form heights from 7" to 11". (This product)
• Cost & Labor Efficient: The quick snap-in installation drastically reduces labor time. The recommended 18" spacing and reusability of the brackets lower overall material expenses compared to traditional forming methods.
• Clean & Damage-Free Removal: Since the brackets snap into a disposable shoe, they can be removed easily without damaging the concrete slab, leaving a clean surface ready for the next phase of construction.

How It Works & Best Practices

1. Prepare the Surface: Ensure the casting slab surface is clean, dry, and free of dust or debris for optimal adhesion of the shoe plate.
2. Position the Shoe Plate: Lay out your form lines and stick the adhesive-backed shoe plates along the line at a maximum spacing of 18 inches.
3. Install the Bracket & Form: Snap the 7" Tilt Bracket™ firmly into each shoe plate. Set your form board (e.g., 2x8 or 2x12 lumber) into the brackets.
4. Pour Concrete: Proceed with your concrete pour, confident that the forms are securely held in place.
5. Strip the Forms: Once the concrete has cured, simply pull the form boards and snap the brackets out of the shoe plates. The brackets can be cleaned and stored for the next job, while the shoe plates remain on the slab and can be easily scraped off or left in place.

Product Specifications

• Product Name: Dayton Superior Tilt Bracket, 7"
• Package Quantity: 100 Brackets per Carton
• Bracket Height: 7 inches
• Recommended Form Height: 7" to 11"
• Material: High-durability plastic
• Maximum Spacing: 18 inches on center

When precision, efficiency, and reliability are critical, the Dayton Superior Tilt Bracket™ system is the ultimate solution for your tilt-up forming needs. Upgrade your workflow and achieve a superior finish on every project.

Order your carton of 100 today!
