Ultra Low Temperature Dual Probe Data Logger, Software-Less Reporting

Thermco’s new Dual Probe AccuTherm 8019UL data logger is the most powerful logger to date. Monitor two ultra low freezers simultaneously or add the optional ACCRTAMB ambient temperature sensor and log the room temperature, and freezer. The 8019UL can record 24 million records. Each record contains… date, time, sensor temp readings, sensor status: normal – hi alarm – low alarm – sensor failure, and % of battery power remaining. AccuTherm 8019UL is a self-contained data logger that requires No PC Software to generate a complete Excel .csv report. Large easy to read display for viewing both channels current-min-max temperatures plus time and battery status. Each data logger is certified, serialized and traceable to NIST from Thermco’s own ISO17025 calibration laboratory, accredited by ILAC-mra to assure accuracy and compliance with all regulatory requirements. (accreditation no. 69071)

FEATURES:

• NIST Traceable Certificate
• High Accuracy ±0.3°C (±0.6°F)
• Log 24 Million Readings on 2G Micro SD Card
• Data File in Excel .csv Format
• Retrieve Data from Logger with Removable
  SD Memory Card or by USB cable to PC
• Logger Records Date, Time, P1 Temp, P2 Temp and Battery Level into .csv file
• Logging Interval Selectable from 1 to 720 Minutes
• Large LCD Display shows Current Min Max Temperature for each Sensor
  plus Time and Low Battery Indication
• User Adjustable Low and High Alarm Limits Setting for Each Sensor
• Audible and Flashing LED Alarm Indicators
• Temperatures in °C or °F
• Time in 12 or 24 Hour Format
• Flip Out Desk Stand
• Battery Life About 10 Months in Continuous Operation with no alarm triggered

SPECIFICATIONS:

Measuring Range of Stainless Steel Temperature Probes: -80~70°C (-112~158°F)

Display Accuracy ±0.3°C (±0.6°F) Over Full Range

Display Resolution 0.1°

Display Reading Update 10 Seconds

Memory Removable 2G Micro Sd Card (Max: 4G)

Memory Capacity 24 Million Readings

Data Logging Interval Once Per Minute to Once Per 720 Minutes User Option

Alarm Limit Setting Resolution 0.1°

Default Alarm Value Low -10°C, High 50°C

Time Accuracy ±1 Second Per Day

Time Display Format 12/24 Hour Format User Option

Effective Calendar Period 2016 – 2099

Battery 1.5 Volt Type AAA x 3 Pieces

Battery Life About 8000 Hours In Continuous Operation with No Alarm Triggered

Working Ambient Temperature 0 to 50°C (32 to 122°F)

Display Size 54(W) X 64(H) mm

External Sensor Cable Length 2 meter / 6 feet

Product Size 83 (W) X 120 (H) X 26 (D) mm
